A11VO Axial Piston Pump Open Circuit Hydraulic System Rexroth A11VO95 for Tractor Product Type Hydraulic Pumps
$2,000.00
وصف
| Parameter | Value |
|---|---|
| Model | A11VO95DRS/10R-NSD12K02 |
| Displacement | 93.5 cm³ (5.71 in³/rev) |
| Max Operating Pressure | 400 bar (5800 psi) |
| Speed Range | 2350-2780 RPM |
| Flow Rate | 220 L/min (58.1 GPM) |
| Torque | 521 Nm @ 400 bar |
| Control Type | Hydraulic displacement control |
| Weight | 70 kg |
| Port Size | SAE 12 (DN32) |
| Motor Power | 128 kW @ 400 bar |
| Efficiency | ≥92% (volumetric) |
| Noise Level | <85 dB(A) |
| Fluid Temperature | -20°C to +80°C |
| Fluid Viscosity | 15-1600 mm²/s |
| Warranty | 6 months |
| Certification | ISO 4401, CETOP RP121H |
| Stock Status | Available |
| Delivery Time | 1-15 days after payment |
